Product Details
| Item |
Details |
| Application Areas |
Widely used in large – scale construction projects, such as commercial complexes and super – high – rise buildings; infrastructure construction, including airport runways and port terminals; industrial plant construction, as well as large – scale water conservancy and hydropower projects, such as dam and hydropower station construction |
| Applicable Materials |
Can mix various types of concretes, such as ordinary concrete, high – strength concrete, impermeable concrete, mass concrete, etc., as well as various construction mortars and refractory materials |
| Mixing System |
The mixing tank has a capacity of 4.5 cubic meters, with a frame – type mixing structure design. It is equipped with multiple sets of mixing blades at different angles, and the rotation speed of the mixing shaft is adjustable between 20 – 45 revolutions per minute. The mixing blades are made of high – strength and corrosion – resistant alloy materials, and have undergone special surface treatment, with strong wear – resistance. The discharge port adopts a large – caliber design, with a width of 0.7 meters, and is equipped with an electric – hydraulic unloading device, with fast and clean unloading |
| Production Capacity |
The mixing volume per batch is 4.5 cubic meters, and 4 – 6 batches can be mixed per hour, with a production efficiency of 16 – 24 cubic meters per hour, meeting the concrete supply needs of large – scale construction |
| Power System |
Equipped with Shangchai SC9DK280Q5 engine, 6 – cylinder in – line, turbocharged and intercooled, with a power of 206KW and a rotation speed of 2200rpm, providing strong power and high reliability |
| Transmission Method |
Adopts a combination of gear reducer and chain drive to ensure the stable and efficient operation of the mixing shaft. The gear reducer has the characteristics of high precision and large torque, and the chain drive ensures the stability and reliability of power transmission |
| Travel Mechanism |
Adopts 10 – wheel drive, equipped with specially made ultra – wide engineering tires, with a specification of 24.5/70 – 26. The tire tread pattern is uniquely designed, with strong grip, adapting to various complex road surfaces. The maximum traveling speed is 32 km/h, facilitating flexible movement at the construction site |
| Operation Control |
Equipped with a full – color touch – type intelligent operation screen, with a simple and easy – to – understand interface. It can achieve remote operation and monitoring. Operators can accurately set parameters such as mixing time, speed, and material ratio on the operation screen, and view the real – time operating status and fault alarm information of the equipment |
| Water Supply System |
Four 500 – liter polyethylene water tanks are provided, and a 72V DC high – pressure pump is used for water supply, with stable water pressure and large flow rate. An automatic cleaning spray head is equipped to comprehensively clean the inside of the mixing tank, the discharge port, and its surroundings |
| Safety Protection |
Multiple safety protection measures are configured, including overload protection, short – circuit protection, leakage protection, over – temperature protection, emergency stop button, etc. A sturdy protective fence is installed around the mixing tank to prevent accidental approach of personnel to rotating parts |
| Weight |
The total weight of the machine is approximately 12000kg, with a sturdy structure and good stability |
| Overall Dimensions |
7.5 meters in length, 3.2 meters in width, and 4.5 meters in height, facilitating transportation and layout at large – scale construction sites |
| Measurement System |
High – precision electronic weighing sensors are used to accurately measure materials, with an error controlled within ±0.1%. An intelligent flow sensor is equipped to precisely control the amount of water added, ensuring the high accuracy of the concrete mix ratio |
Product Features
1. Wide applicability:
It can play a role in all kinds of large-scale construction projects, from commercial complexes, super high-rise buildings, to infrastructure construction such as airport runways and port terminals, as well as industrial plants, water conservancy and hydropower projects, covering a wide range of fields. At the same time, it can handle a variety of concrete and building mortar, refractory materials and other materials to meet the needs of different projects.
2. Efficient mixing performance:
4.5 cubic meters of large-capacity mixing tank, with frame-type mixing structure and multiple sets of mixing blades at different angles, the mixing shaft speed is adjustable from 20 to 45 rpm to ensure that the material is fully mixed. High-strength, corrosion-resistant and specially surface-treated alloy mixing blades have strong wear resistance and extend the service life of the equipment. The large-diameter discharge port is equipped with an electric hydraulic discharge device for fast and clean unloading.
3. Strong production capacity:
The mixing volume of each batch is 4.5 cubic meters, 4 to 6 batches can be mixed per hour, and the production efficiency is 16 to 24 cubic meters/hour, which can continuously and stably supply concrete for large-scale construction.
4. Stable power output:
Shanghai Diesel SC9DK280Q5 engine, 6-cylinder in-line, turbocharged intercooler, 206KW power and 2200rpm speed, strong power and high reliability, providing solid guarantee for the stable operation of the mixer.
5. Reliable transmission mode:
Gear reducer combined with chain drive, gear reducer with high precision and high torque, chain drive ensures stable and reliable power transmission, ensuring stable and efficient operation of the mixing shaft.
6. Good mobility:
10-wheel drive with 24.5/70-26 special ultra-wide engineering tires, unique pattern design makes it have strong grip, adapt to a variety of complex road surfaces, and a maximum driving speed of 32 kilometers per hour, which is convenient for flexible movement on the construction site.
7. Intelligent operation experience:
full-color touch-screen intelligent operation screen, simple and easy-to-understand interface, supports remote operation and monitoring. Operators can accurately set mixing parameters and view equipment operation status and fault alarm information in real time.
8. Stable water supply and cleaning:
Four 500-liter polyethylene water tanks, water is supplied by a 72V DC high-pressure pump, with stable water pressure and large flow. The automatic cleaning nozzle can clean the mixing tank and its surroundings in all directions.
9. Complete safety protection:
Multiple safety protection measures such as overload, short circuit, leakage, overtemperature protection and emergency brake button, combined with solid guardrails around the mixing tank, fully guarantee the safety of personnel and equipment.
10. Accurate metering system:
High-precision electronic weighing sensor, material metering error is controlled within ±0.1%, and the intelligent flow sensor accurately controls the amount of water added to ensure that the concrete ratio is highly accurate and the quality of the project is guaranteed.
Application
The 4.5 Cubic Cement Mixer Truck is highly versatile in construction. In commercial complex construction, its large production capacity of 16 – 24 cubic meters per hour enables rapid completion of large – scale concrete pouring, reducing construction time. For airport runway construction, the precise measurement system, with an error within ±0.1%, ensures the high – quality concrete required for the runway. In large – scale hydropower station projects, the strong and reliable Shangchai engine and stable transmission system guarantee continuous operation. Also, in the construction of super – high – rise buildings, the intelligent operation control allows for remote management, enhancing construction efficiency in complex environments.
